KP5 Danfoss Pressure switch high pressure solder 060118066

KP5 Danfoss Pressure switch High Pressure 1/4" solder 060-118066

Ambient temperature [°C] -40 - 65 °C

Ambient temperature [°F] -40 - 149 °F

Ambient temperature range [°C] -40 - 65 °C

Ambient temperature range [°F] -40 - 149 °F

Approval BV, c UL us UL873, CS C22.2, CCC, CE, DNV, GL, LR, RINA, RMRS

Contact function SPDT

Contact rating AC1=16 A, 400 V

Contact rating AC15=10 A, 400 V

Contact rating AC3=16 A, 400 V

Contact rating DC13=12 W, 220 V

Contact rating LR 112 A, 400 V

Differential [bar] 3,00 bar

Differential [psi] 43,00 psi

EAN number 5702428011853

Electrical connections comments Rubber cable gland

Electrical connection size 6-14 mm

Enclosure rating IP30

Max. test pressure [bar] Pe 35,0 bar

Max. Working Pressure [bar] 35,0 bar

Max. Working Pressure [psig] 510 Psig

Max. Working Pressure [bar] Pe 35,0 bar

Max. Working Pressure [psig] Pe 510,0 psig

Nema Rating 1

Pressure connection Solder, ODF 1/4

Pressure connection standard ISO 2016

Pressure Male/Female Female

Pressure range category HIGH PRESSURE

Pressure sensing element Bellows

Product description Pressure control

Refrigerant(s) HCFC

Refrigerant(s) Non flam HFC

Regulation range [bar] Pe 8,00 - 32,00 bar

Regulation range [psig] Pe 116,00 - 464,00 psig

Reset function Max

UL approval file name E31024
